AFG-4125E
AFG-4125E - Image 2
AFG-4125E - Image 3

AFG-4125E

CHF 314.00
excl. VAT

GW Instek
Arbitrary, 25 MHz, 25 MHz, Arbitrary, 1-CH, 14-bit, USB Device, 125 MSa/s, Short-circuit protection, 16 kpts, 8-inch TFT LCD, 3FSK
Wishlist
SKU: SH1559 Category: Brand:

Description

GW Instek AFG-4125E 25 MHz 1-Channel Arbitrary Function Generator

The GW Instek AFG-4125E is a 25 MHz, 1-channel arbitrary function generator from the AFG-4000 series with 125 MSa/s sample rate, 14-bit resolution and an 8-inch display.

Key Specifications

  • Max. frequency: 25 MHz sine
  • Channels: 1
  • Sample rate: 125 MSa/s
  • Vertical resolution: 14 bits
  • Memory: 16 kpts per channel
  • Frequency resolution: 1 µHz
  • Display: 8-inch TFT LCD, 800 × 480

Waveforms & Modulation

  • Waveforms: sine, square, triangle, ramp, pulse, noise, harmonic, arbitrary (146 built-in)
  • Modulation: AM, DSB-AM, FM, PM, PWM, ASK, PSK, BPSK, QPSK, FSK, 3FSK, 4FSK, OSK, SUM
  • Built-in sweep, burst and frequency counter; 50 ohm / high-impedance switching

Connectivity

  • USB Host, USB Device

Additional information

Functions

, , , , , , , , ,

Bandwidth (MHz)

Frequency Range

25 MHz
Waveform

Channels

1-CH
Res

Interface

,

Sample Rate:

Sync

Protection

Memory:

Display

Modulation

3FSK, 4FSK, AM, ASK, BPSK, DSB-AM, FM, FSK, OSK, PM, PSK, PWM, QPSK, SUM

Available Technical Documents

Optional Add-ons

Related Products

  • TGP3121

    CHF 1'440.00
    excl. VAT
    AM, 25 MHz, Pulse Gen, 1-CH, 800 MSa/s, <30 ps, GPIB optional

    1 CH, 25 MHz pulse generator, 20 ns width, 8 ns edges, < 30 ps jitter, 800 MSa/s arb, USB/LAN (GPIB opt.)

    View product
    Wishlist

  • TG5011A

    CHF 883.00
    excl. VAT
    AM, 50 MHz, 50 MHz, Arb/Function, 1-CH, 125 MSa/s, 14-bit, 128 kpts, GPIB optional, 256 × 112, AM

    1 CH, 50 MHz, 125 MSa/s, 14-bit, 128k-point arb, AM/FM/PM/FSK/BPSK, USB/LAN (GPIB opt.)

    View product
    Wishlist

  • TGR2051-U01
