AFG-4225H
AFG-4225H - Image 2
AFG-4225H - Image 3

AFG-4225H

CHF 1'143.00
excl. VAT

GW Instek
Arbitrary, 250 MHz, 250 MHz, Arbitrary, 2-CH, 1.25 GSa/s, LAN, 10 Mpts, 16-bit, 3FSK, 8-inch multi-touch TFT
Wishlist
SKU: SH1572 Category: Brand:

Description

GW Instek AFG-4225H 250 MHz 2-Channel Arbitrary Function Generator

The GW Instek AFG-4225H is a 250 MHz, 2-channel arbitrary function generator from the AFG-4000 series with 1.25 GSa/s sample rate, 16-bit resolution and an 8-inch multi-touch display.

Key Specifications

  • Max. frequency: 250 MHz sine
  • Channels: 2
  • Sample rate: 1.25 GSa/s
  • Vertical resolution: 16 bits
  • Memory: 10 Mpts per channel
  • Frequency resolution: 1 µHz
  • Display: 8-inch multi-touch TFT, 800 × 480

Waveforms & Modulation

  • Waveforms: sine, square, triangle, ramp, pulse, noise, harmonic, arbitrary (146 built-in)
  • Modulation: AM, DSB-AM, FM, PM, PWM, ASK, PSK, BPSK, QPSK, FSK, 3FSK, 4FSK, OSK, SUM
  • Built-in sweep, burst and frequency counter; 50 ohm / high-impedance switching

Connectivity

  • USB Host, USB Device, LAN

Additional information

Functions

, , , , , , , , ,

Bandwidth (MHz)

Frequency Range

250 MHz
Waveform

Channels

2-CH
Sample Rate:

Interface

, ,

Memory:

Res

Modulation

3FSK, 4FSK, AM, ASK, BPSK, DSB-AM, FM, FSK, OSK, PM, PSK, PWM, QPSK, SUM
Display

Available Technical Documents

Optional Add-ons
