KEYSIGHT – DSOX1204A

The Keysight DSOX1204A is part of the InfiniiVision 1000 X-Series and delivers reliable performance with the added flexibility of four analog channels. Designed for engineers, technicians, and educational environments, it provides essential measurement capability in a space-saving and cost-effective platform.

Ideal for multi-signal debugging and general-purpose testing, the DSOX1204A combines professional quality with intuitive operation.

Product Highlights

Expanded Channel Capability

• 70 MHz bandwidth

• 4 analog channels

• Up to 2 GSa/s sampling rate

• Up to 2 Mpts memory depth

Analyze multiple signals simultaneously without external switching.

Clear & Detailed Visualization

• 7-inch WVGA display

• Intensity-graded waveform display for improved visibility

• Fast waveform update rate for capturing signal anomalies

Comprehensive Measurement Functions

• 24 automatic measurements including voltage, time, and frequency parameters

• Built-in math functions such as FFT, addition, subtraction, and multiplication

• Advanced triggering modes for stable signal acquisition

Flexible & Upgradeable

• Optional serial protocol triggering and decoding (I²C, SPI, UART, CAN, LIN)

• USB connectivity for data storage and remote control

• Compatible with standard Keysight probes

A scalable solution that adapts to evolving measurement needs.

Key Specifications at a Glance

• 70 MHz bandwidth

• 4 analog channels

• Up to 2 GSa/s sampling rate

• Up to 2 Mpts memory

• 7-inch WVGA display

• Compact, bench-friendly design

Ideal For

Electronics development
Embedded system debugging
Industrial service and maintenance
Educational laboratories
Multi-channel signal analysis

The Keysight DSOX1204A offers dependable performance and four-channel flexibility in a compact oscilloscope ” making it a practical and versatile solution for everyday testing and development tasks.
