EMS08R+

Description

High-Resolution Radiated Emission Diagnostic Platform

Advanced Automated PCB Radiated EMI Scanning for Professional EMC Labs

The Y.I.C EMScannerR+ is a high-performance automated EMI pre-compliance scanning system engineered for precise PCB-level radiated emission diagnostics. Designed for advanced EMC development and high-speed electronic systems, the EMScannerR+ delivers enhanced spatial resolution, expanded frequency coverage, and improved correlation to formal chamber testing.

It enables engineering teams to detect, localize, and quantify EMI sources early in the design cycle ” reducing compliance risk and shortening time-to-market.

---

Product Highlights

Automated High-Resolution Near-Field Scanning

• Dense near-field probe array

• Automated X-Y PCB scanning system

• High spatial emission resolution

• Precise radiated EMI hotspot localization

Identify emission sources such as high-speed signal lines, switching nodes, return path discontinuities, and shielding weaknesses.

---

Enhanced Radiated Pre-Compliance Capability

• Frequency-selective emission scanning

• Radiated emission diagnostics at PCB level

• Improved correlation to CISPR / FCC chamber measurements

• Comparative analysis across design revisions

The EMScannerR+ supports structured EMI root-cause analysis and systematic EMC optimization.

---

Advanced Software & Analysis Tools

• 2D and 3D emission heat maps

• Frequency-domain spectral visualization

• Peak, average and advanced detection modes

• Design comparison tools

• Automated reporting and exportable engineering data

The powerful software environment enables detailed emission analysis and professional documentation.

---

Technical Advantages for EMC Engineers

• Repeatable automated scanning process

• Reduced dependency on external pre-test facilities

• Faster EMI troubleshooting and layout optimization

• Quantitative spatial emission measurement

• Improved first-pass compliance probability

Designed for professional EMC laboratories and advanced hardware development teams.

---

Key Capabilities at a Glance

• Automated PCB radiated emission scanning

• High-resolution spatial emission mapping

• Pre-compliance reference validation

• Advanced spectral and comparative analysis

• Engineering-grade reporting tools

---

Ideal For

EMC / EMI engineers
High-speed digital PCB development
Automotive electronics
Industrial and power electronics
Advanced R&D laboratories
Pre-certification EMC validation

---

The Y.I.C EMScannerR+ combines high-resolution near-field scanning with advanced radiated emission analysis ” providing a powerful in-house diagnostic solution for professional EMC engineering

---

Why Choose the EMS08R+?

The EMS08R+ is built to deliver unmatched reliability and accuracy in the most demanding environments. Designed for engineers who prioritize performance, this unit ensures stable results for R&D, quality assurance, and industrial maintenance. Contact us today for personalized technical support and bulk inquiries.
