AFG-4225E
AFG-4225E - Image 2
AFG-4225E - Image 3

AFG-4225E

CHF 425.00
excl. VAT

GW Instek
Arbitrary, 25 MHz, 25 MHz, Arbitrary, 2-CH, 125 MSa/s, USB Device, 10 Mpts, 14-bit, 8-inch TFT LCD, 3FSK
Wishlist
SKU: SH1567 Category: Brand:

Description

GW Instek AFG-4225E 25 MHz 2-Channel Arbitrary Function Generator

The GW Instek AFG-4225E is a 25 MHz, 2-channel arbitrary function generator from the AFG-4000 series with 125 MSa/s sample rate, 14-bit resolution and an 8-inch display.

Key Specifications

  • Max. frequency: 25 MHz sine
  • Channels: 2
  • Sample rate: 125 MSa/s
  • Vertical resolution: 14 bits
  • Memory: 10 Mpts per channel
  • Frequency resolution: 1 µHz
  • Display: 8-inch TFT LCD, 800 × 480

Waveforms & Modulation

  • Waveforms: sine, square, triangle, ramp, pulse, noise, harmonic, arbitrary (146 built-in)
  • Modulation: AM, DSB-AM, FM, PM, PWM, ASK, PSK, BPSK, QPSK, FSK, 3FSK, 4FSK, OSK, SUM
  • Built-in sweep, burst and frequency counter; 50 ohm / high-impedance switching

Connectivity

  • USB Host, USB Device

Additional information

Functions

, , , , , , , , ,

Bandwidth (MHz)

Frequency Range

25 MHz
Waveform

Channels

2-CH
Sample Rate:

Interface

,

Memory:

Res

Sync

Display

Modulation

3FSK, 4FSK, AM, ASK, BPSK, DSB-AM, FM, FSK, OSK, PM, PSK, PWM, QPSK, SUM

Available Technical Documents

Optional Add-ons
